AQUILA 5 - FALL ARREST HARNESS
AQUILA 5 is a harness from the Basic range, light and easy to adjust to the user thanks to its 5 adjustment points on the shoulders, chest and legs. It's constructed in two colors for easy orientation when dressing and contrasting gray seams allow for easy inspection of the harness, as well as the fall indicators. It has a back D-ring (A - EN361) and two front loops (1/2 A + 1/2 A - EN361). The buckles on the legs are Deluxe and allow for a quicker tightening.
SCAFFOLDING
ROOF WORKS
CONSTRUCTION
TECHNICAL INFORMATION
| LIFESPAN | 10 |
|
|
|
| MAXIMUM LOAD | CE - 140kg |
|
|
|
| INSPECTION | Yearly |
|
|
|
| TRACEABILITY | S/N QR Code |
|
|
|
| STANDARDS | CE - EN361:2002 |
|
|
|
| INTRASTAT | 63079098 |
|
|
|
| METAL PARTS | Steel |
|
|
|
| TEXTILE PARTS | Polyester |
|
|
|
| OTHER COMPONENTS MATERIAL | Silicone |
|
|
|
| WEBBING TYPE | PES webbing 45mm high visibility; PES elastic webbing 45mm black; PES webbing 45mm black |
|
|
|
| D-RINGS | ST D-ring at back, 2 front loops |
|
|
|
| ANCHOR POINTS (A) | 2 |
|
|
|
| SHOULDER PADDING | No |
|
|
|
| LEG PADDING | No |
|
|
|
| SEAT CONNECTION POINT | No |
|
|
|
| TOOL HOLDERS | No |
|
|
|
| ADJUSTMENT POINTS | 5 |
|
|
|
| BUCKLES | 2 ST Deluxe buckle; 2 ST bar buckles; 1 delta steel buckle |
|
|
|
| FALL ARREST INDICATORS | Yes |
|
|
|
| LANYARD KEEPERS | No |
|
|
|
| WEIGHT PER SIZE EAN/UPC PER SIZE | FS2018 - 1.16kg - 5605423752397 |
|
|
|
